100pF 50V Mini Ceramic Capacitor (101)
= Precision High-Frequency Capacitor for RF, Oscillator, and Timing Applications =
The 100pF (0.1nF) ceramic capacitor is a standard EIA value ideal for crystal oscillator circuits, RF decoupling, highfrequency filtering, and precision timing applications. This "mini" capacitor is available in both throughhole and surface-mount packages to suit various PCB designs.
Capacitance: 100pF = 0.1nF = 0.0001µF (marked as "101")
Voltage Rating: 50V DC
Common applications: Crystal oscillators, RF decoupling, high-frequency bypass, and EMI suppression
Do not exceed the rated 50V derating is recommended for reliable longterm operation
Class II dielectrics (X7R, X5R, Y5V) can lose capacitance under DC bias
= Available Package Options =
The 100pF 50V capacitor is available in multiple form factors to suit different applications:
| Package Type | Dielectric | Tolerance | Temperature Range | Common Use |
|---|
| Through-Hole Radial | X7R | ±10% | -55°C to +125°C | Hobbyist, breadboard, prototyping |
| Through-Hole Radial | Y5V | +80/-20% | -30°C to +85°C | Generalpurpose, costsensitive |
| SMD 0603 | X7R | ±10% | -55°C to +125°C | Compact, high-density PCB designs |
| SMD 0805 | X7R | ±10% | -55°C to +125°C | General-purpose SMD applications |
| SMD 1206 | NP0/C0G | ±5% | -55°C to +150°C | Highstability, AECQ200 automotive |
| SMD 1206 | X7R | ±10% | -55°C to +125°C | Higher power handling |
= Key Features =
Standard EIA Value - 100pF is a commonly used and readily available capacitance value
NonPolarized Easy assembly with no polarity concerns
Wide Temperature Range X7R grade offers 55°C to +125°C operation
Multiple Package Options Available in throughhole radial and SMD (0603, 0805, 1206) formats
== Applications ==
- Crystal oscillator loading circuits (commonly used with 8-16MHz crystals)
- RF decoupling for sensitive RF and communication circuits
- High-frequency bypass on power supply lines
- Noise suppression on data and signal lines
- EMI/RFI filtering at circuit inputs and outputs
- Timing and delay circuits
- Automotive electronics (AEC-Q200 variants available)
- High-speed digital circuits
Standard EIA Value - 100pF is a commonly available capacitance value
AECQ200 Available Automotive-grade variants available for harsh environments
√ Ready to use - no polarity for easy assembly
√ Stable performance over wide temperature range (X7R grade)
√ Excellent high-frequency characteristics for clean power delivery
= Package Includes =
Varies by seller:
- Bulk packs (throughhole radial) 10 to 500+ pieces
- Tape and reel (SMD) - 100 to 10,000+ pieces
- Cut tape / loose pieces for prototyping
The "101" marking indicates 100pF - first two digits are significant, third is multiplier (10 x 10¹ = 100pF)
For crystal oscillator circuits, 100pF is commonly used for crystal loading - check your crystal datasheet for exact value
For RF decoupling, place capacitor as close as possible to the IC power pin
For highreliability applications, select NP0/C0G or AECQ200 rated variants
For precision timing circuits, use NP0/C0G dielectric for ±30ppm/°C temperature stability
For automotive applications, select AEC-Q200 qualified variants with higher temperature ratings
Avoid using highK dielectrics (X7R, Y5V) in precision timing circuits - capacitance varies with DC bias and temperature
Avoid exceeding rated voltage for 50V rated parts, recommended operating voltage is typically ≤40V
Avoid placing decoupling capacitors too far from ICs increased trace inductance reduces high-frequency effectiveness
