BPW34 Photodiode

SKU: HMJ508 Category: Intergrated circuits
KSH 100.00
In Stock
Inquire
Product Description

BPW34 Silicon PIN Photodiode

= High-Speed Light and Infrared Sensor for Arduino and DIY Projects =

The BPW34 is a highspeed, generalpurpose PIN photodiode from Vishay. Its fast response time and sensitivity to visible and near-infrared light make it a popular choice for remote controls, light detection, and even creative DIY projects like shutter speed timers or radiation detectors .

HighSpeed Detection 100ns rise/fall time allows for fast light pulse detection
Wide Spectral Sensitivity - Detects light from 430nm to 1100nm, covering both visible and IR ranges
Operating temperature range is -40°C to +100°C .
The BPW34 can be used in photovoltaic mode (like a solar cell) or photoconductive mode (faster response) .
The component is sensitive to a wide range of light. To detect only specific wavelengths, a filter may be required .

= Technical Specifications =

ParameterValue
----
Wavelength Range430nm to 1100nm
Peak Sensitivity900nm
Radiant Sensitive Area7.5mm²
Switching Speed (Rise/Fall)100ns (typ.)
Dark Current2nA (typ.)
Open Circuit Voltage350mV (typ.)
PackageDIP (Through-hole, clear plastic)

= Key Features =

High Radiant Sensitivity - Detects low light levels effectively .

Miniature, Flat Package - Fits easily into compact designs and breadboards .

Fast Response Times Ideal for applications involving highspeed light pulses and data transmission .

Sensitive to Visible & NIR - Versatile for use in IR remote controls, ambient light sensors, and more .

== Applications ==

  1. IR remote control receivers for TVs, hi-fi, and dimmers .
  2. Photointerrupters and industrial control systems .
  3. DIY light detection projects, such as shutter speed timers or light meters .
  4. High-speed photo detectors in data communication .
Versatile Performance - A flexible component suitable for many sensing projects
LongStanding Standard A reliable and well-documented industry staple

√ DIP package is compatible with standard 2.54mm breadboards and perfboards

√ Sensitive to both visible and IR light
