The SRA12VDCCL is a highperformance 5pin power relay designed for switching heavy loads with a low-power control signal. Featuring a 12V DC coil and SPDT (Single Pole Double Throw) contacts, this relay is ideal for Arduino, ESP32, and industrial automation projects requiring reliable load switching.
| Parameter | Value |
|---|---|
| Manufacturer | Songle Relay |
| Coil Voltage | 12V DC |
| Coil Resistance | 400Ω ±10% |
| Coil Power | 360mW |
| Contact Form | 1C (SPDT - Single Pole Double Throw) |
| Pin Count | 5 Pins |
| Contact Rating | 20A @ 14V DC |
| Max Switching Voltage | 125V AC |
| Max Switching Current | 10A |
| Contact Resistance | ≤100mΩ |
| Operate Time | 10ms |
| Release Time | 10ms |
| Operating Temp | -40°C ~ +85°C |
| Dimensions | 16 x 12.4 x 14.2mm |
| Mounting | Through-hole PCB |
| Pin | Function | Description |
|---|---|---|
| 1 | Coil (+) | Positive coil terminal (12V) |
| 2 | Coil (-) | Negative coil terminal (GND) |
| 3 | COM | Common terminal |
| 4 | NC | Normally Closed (connected to COM when relay off) |
| 5 | NO | Normally Open (connected to COM when relay on) |
√ Compatible with Arduino, ESP32, PLC systems
√ Excellent for automotive, industrial, and DIY projects
√ Low 360mW coil consumption
√ Clear markings for easy identification
√ Proven reliability in demanding applications
The SRA12VDCCL is a versatile, highcurrent relay perfect for switching loads in Arduino, automation, and automotive projects. Reliable, compact, and easy to use the ideal choice for your next project.
