D1 Mini ESP8266 WiFi Development Board
= Compact Arduino-Compatible IoT Module for DIY Projects =
The D1 Mini is a miniature WiFi development board based on the ESP8266 ESP12F module, packing a Tensilica L106 32bit RISC processor, 4MB flash, and integrated 2.4GHz WiFi into a tiny 34.2×25.6mm PCB. Its breadboard-friendly form factor and shield ecosystem make it a popular choice for DIY IoT projects like smart switches, sensors, and robotics.
Compact ESP8266 Board - Small footprint with 80/160MHz CPU and 4MB flash for versatile projects
ArduinoCompatible Programmable via Arduino IDE, MicroPython, and NodeMCU
Power via Micro-USB (5V) or through the 5V pin. All GPIO pins operate at 3.3V logic.
The onboard CH340 USBtoserial chip simplifies programming; no external programmer needed.
I/O pins are not 5V tolerant - applying 5V to GPIO pins will permanently damage the board.
= Technical Specifications =
| Parameter | Value |
|---|
| Microcontroller | ESP8266EX (ESP-12F module) |
| CPU | Xtensa L106 32-bit RISC |
| Clock Speed | 80MHz / 160MHz |
| Flash Memory | 4MB (32Mbit) |
| SRAM | ~80KB usable |
| Wi-Fi | 802.11 b/g/n (2.4GHz) |
| Digital I/O Pins | 11 (all support PWM/I2C/One-Wire) |
| Analog Input | 1 pin (0-3.2V max) |
| USB Connector | Micro-USB (CH340/CH9102 bridge) |
| Dimensions | 34.2mm × 25.6mm |
= Key Features =
Integrated WiFi 802.11 b/g/n Supports STA, AP, and STA+AP modes
Onboard USBtoSerial Bridge - Direct USB programming, no external adapter required
BreadboardFriendly Design Standard 2.54mm pin headers with stackable shield ecosystem
Builtin LED on D4/GPIO2 User-controllable for status indication
All GPIOs Support PWM/I2C/OneWire Except D0
== Applications ==
- Smart home automation and sensor networks
- Wi-Fi remote control and monitoring devices
- LED matrix displays and lighting projects
- Energy and gas meter monitoring systems
- Quadruped robots and robotics projects
Affordable IoT Platform Budgetfriendly entry into WiFiconnected projects
Huge Ecosystem - Extensive library support and community examples
√ Compatible with Arduino IDE (select "NodeMCU 1.0 (ESP-12E Module)")
√ Supports MicroPython, TinyGo, and NodeMCU firmware
√ Available with pre-soldered headers for immediate breadboard use
