STM32G030C8T6 Mini Development System Board Module STM32G030 STM32 G030 MCU M0 Microcontroller Core Learning Chip

SKU: HMJ700 Category: Microcontrollers
KSH 950.00
Out of Stock
Inquire
Product Description

STM32G030C8T6 Mini Development System Board

= STM32G030 M0 Core MCU Learning Module =

The STM32G030C8T6 is a compact development board built around the Arm CortexM0+ core. It serves as a costeffective platform for learning ARM programming and prototyping embedded applications, featuring 64KB Flash and 8KB RAM.

HighPerformance M0+ Core Runs at 64MHz for responsive processing
Compact BreadboardFriendly Design Easy to integrate into prototypes
Supply voltage is 5V via USB, regulated onboard to 3.3V
Use an ST-Link programmer (SWD interface) for uploading code
This chip does NOT support native USB programming

= Technical Specifications =

ParameterValue
CoreARM CortexM0+ 32bit
Clock SpeedUp to 64 MHz
Flash Memory64 KB
SRAM8 KB
Operating Voltage2.0V to 3.6V (Core) / 5V (USB)
GPIO PinsUp to 37 accessible via headers
ADC12-bit with up to 16 channels
Communication2x I2C, 2x USART, 2x SPI

= Key Features =

Rich Peripheral Set Includes advancedcontrol PWM timer and RTC

Flexible Power Options USBC or external 5V via pin header

Onboard Resources - 8MHz and 32.768kHz crystals for precise timing

User Interface - Includes RGB LED and reset button

External Storage - Some variants include onboard I2C EEPROM

== Applications ==

  1. Learning ARM Cortex-M0+ programming
  2. IoT and sensor node prototyping
  3. Motor control and PWM applications
  4. Industrial control and automation
  5. Batterypowered lowpower devices
Modern Architecture - Upgrades from older STM32F0 series
Extensive Ecosystem - Supports STM32CubeIDE and Arduino IDE

√ Ideal for educational and hobbyist projects

√ STM32duino compatible

√ Breadboard-friendly form factor

= Development and Programming =

The board supports multiple development environments:

  • STM32CubeIDE (official ST toolchain)
  • Arduino IDE via the STM32duino core
  • Keil MDK and IAR Embedded Workbench

Programming Method: Use an ST-Link V2 programmer connected to the SWD interface. The USB port is for power only .

Use STM32CubeMX for easy peripheral configuration
For Arduino IDE, select the "STM32G0 Series" board package
Does NOT support direct USB programming like some other boards
Use an external programmer (ST-Link) for uploading code

= Troubleshooting =

Board not recognized:

  • Use ST-Link V2 programmer for programming
  • USB port is power only
  • Install STM32CubeProgrammer or STM32duino core

Firmware upload fails:

  • Check SWD connections (SWCLK, SWDIO, GND)
  • Ensure board is powered (USB connected)
  • Avoid using USB-TTL adapters for programming
